NA-pad blink events / missing data

Source: R/pipeline-deblink.R
deblink.Rd

Deblinking (a.k.a. NA-padding) of time series data. The intended use of this method is to remove blink-related artifacts surrounding periods of missing data. For instance, when an individual blinks, there are usually rapid decreases followed by increases in pupil size, with a chunk of data missing in-between these 'spike'-looking events. The deblinking procedure here will NA-pad each missing data point by your specified number of ms.

Usage

deblink(eyeris, extend = 40)

Arguments

eyeris

An object of class eyeris dervived from load().

extend

Either a single number indicating the number of milliseconds to pad forward/backward around each missing sample, or, a vector of length two indicating different numbers of milliseconds pad forward/backward around each missing sample, in the format c(backward, forward).

Value

An eyeris object with a new column: pupil_raw_{...}_deblink.

Details

This function is automatically called by glassbox() by default. If needed, customize the parameters for deblink by providing a parameter list. Use glassbox(deblink = FALSE) to disable this step as needed.

Users should prefer using glassbox() rather than invoking this function directly unless they have a specific reason to customize the pipeline manually.

Note

This function is part of the glassbox() preprocessing pipeline and is not intended for direct use in most cases. Provide parameters via deblink = list(...).

Advanced users may call it directly if needed.

See also

glassbox() for the recommended way to run this step as part of the full eyeris glassbox preprocessing pipeline.

Examples

demo_data <- eyelink_asc_demo_dataset()

# 50 ms in both directions
demo_data |>
  eyeris::glassbox(deblink = list(extend = 50)) |>
  plot(seed = 0)
#> ✔ [  OK  ] - Running eyeris::load_asc()
#> ✔ [  OK  ] - Running eyeris::deblink()
#> ✔ [  OK  ] - Running eyeris::detransient()
#> ✔ [  OK  ] - Running eyeris::interpolate()
#> ✔ [  OK  ] - Running eyeris::lpfilt()

#> ! [ SKIP ] - Skipping eyeris::detrend()
#> ✔ [  OK  ] - Running eyeris::zscore()
#> ! Plotting block 1 from possible blocks: 1







# 40 ms backward, 50 ms forward
demo_data |>
  # set deblink to FALSE (instead of a list of params)
  #  to skip step (not recommended)
  eyeris::glassbox(deblink = list(extend = c(40, 50))) |>
  plot(seed = 0)
#> ✔ [  OK  ] - Running eyeris::load_asc()
#> ✔ [  OK  ] - Running eyeris::deblink()
#> ✔ [  OK  ] - Running eyeris::detransient()
#> ✔ [  OK  ] - Running eyeris::interpolate()
#> ✔ [  OK  ] - Running eyeris::lpfilt()

#> ! [ SKIP ] - Skipping eyeris::detrend()
#> ✔ [  OK  ] - Running eyeris::zscore()
#> ! Plotting block 1 from possible blocks: 1
