NA-pad blink events / missing data

Deblinking (a.k.a. NA-padding) of time series data. The intended use of this method is to remove blink-related artifacts surrounding periods of missing data. For instance, when an individual blinks, there are usually rapid decreases followed by increases in pupil size, with a chunk of data missing in-between these 'spike'-looking events. The deblinking procedure here will NA-pad each missing data point by your specified number of ms.

Usage

deblink(eyeris, extend = 50, call_info = NULL)

Arguments

eyeris: An object of class eyeris derived from load_asc()
extend: Either a single number indicating the number of milliseconds to pad forward/backward around each missing sample, or, a vector of length two indicating different numbers of milliseconds pad forward/backward around each missing sample, in the format c(backward, forward)
call_info: A list of call information and parameters. If not provided, it will be generated from the function call

Value

An eyeris object with a new column: pupil_raw_{...}_deblink

Details

This function is automatically called by glassbox() by default. If needed, customize the parameters for deblink by providing a parameter list. Use glassbox(deblink = FALSE) to disable this step as needed.

Users should prefer using glassbox() rather than invoking this function directly unless they have a specific reason to customize the pipeline manually.

Note

This function is part of the glassbox() preprocessing pipeline and is not intended for direct use in most cases. Provide parameters via deblink = list(...).

Advanced users may call it directly if needed.

Examples

demo_data <- eyelink_asc_demo_dataset()

# 50 ms in both directions (the default)
demo_data |>
  eyeris::glassbox(deblink = list(extend = 50)) |>
  plot(seed = 0)
#> ✔ [  OK  ] - Running eyeris::load_asc()
#> ℹ [ INFO ] - Processing block: block_1
#> ✔ [  OK  ] - Running eyeris::deblink() for block_1
#> ✔ [  OK  ] - Running eyeris::detransient() for block_1
#> ✔ [  OK  ] - Running eyeris::interpolate() for block_1
#> ✔ [  OK  ] - Running eyeris::lpfilt() for block_1

#> ! [ SKIP ] - Skipping eyeris::downsample() for block_1
#> ! [ SKIP ] - Skipping eyeris::bin() for block_1
#> ! [ SKIP ] - Skipping eyeris::detrend() for block_1
#> ✔ [  OK  ] - Running eyeris::zscore() for block_1
#>
#> Block processing summary:
#>   block_1: OK (steps: 6, latest: pupil_raw_deblink_detransient_interpolate_lpfilt_z)
#>
#> ✔ [  OK  ] - Running eyeris::summarize_confounds()
#> ! [ INFO ] - Plotting block 1 from possible blocks: 1
#> ℹ [ INFO ] - Plotting with sampling rate: 1000 Hz







# 40 ms backward, 50 ms forward
demo_data |>
  # set deblink to FALSE (instead of a list of params)
  #  to skip step (not recommended)
  eyeris::glassbox(deblink = list(extend = c(40, 50))) |>
  plot(seed = 0)
#> ✔ [  OK  ] - Running eyeris::load_asc()
#> ℹ [ INFO ] - Processing block: block_1
#> ✔ [  OK  ] - Running eyeris::deblink() for block_1
#> ✔ [  OK  ] - Running eyeris::detransient() for block_1
#> ✔ [  OK  ] - Running eyeris::interpolate() for block_1
#> ✔ [  OK  ] - Running eyeris::lpfilt() for block_1

#> ! [ SKIP ] - Skipping eyeris::downsample() for block_1
#> ! [ SKIP ] - Skipping eyeris::bin() for block_1
#> ! [ SKIP ] - Skipping eyeris::detrend() for block_1
#> ✔ [  OK  ] - Running eyeris::zscore() for block_1
#>
#> Block processing summary:
#>   block_1: OK (steps: 6, latest: pupil_raw_deblink_detransient_interpolate_lpfilt_z)
#>
#> ✔ [  OK  ] - Running eyeris::summarize_confounds()
#> ! [ INFO ] - Plotting block 1 from possible blocks: 1
#> ℹ [ INFO ] - Plotting with sampling rate: 1000 Hz
